Detail Vibration Analyzer - 4035
Vibration Analyzer
Model-4035 charge amplifier is to directly amplify output signals transmitted from piezo-electric type pickups for precise measurement of vibration.
SPECIFICATIONS
¦ Frequency Characteristics: 0.5Hz to 100KHz+ 1, -3dB
1Hz to 50KHz± 1dB
5Hz to 20KHz± 0.5dB
¦ Full Scale Sensitivity
Model 4035( Standard Version) : 1V/ 1pC to 10, 000pC
Model 4035-01( High Sensitivity Version) : 1V/ 0.1pC to 1, 000pC
Full-Scale Range of Model-4035 ( Standard Version) is as follows:
1.00 to 9.99pC/ UNIT : 1, 3, 10, 30, 100, 300, 1000UNIT/ FS
10.0 to 99.9pC/ UNIT : 0.1, 0.3, 1, 3, 10, 30, 100UNIT/ FS( in Indicated Values on the Panel) .
100 to 999pC/ UNIT : 0.01, 0.03, 0.1, 0.3, 1, 3, 10UNIT/ FS
¦ Output Characteristics
AC Output: ± 1V/ FS
Non-Distortion Max. Output Voltage: ± 10V( Loaded Resistance: Larger than 10k© )
DC Output: + 1VDC/ FS, 5mA Max.( To call " Model-4035-xx-D"
when ordering)
¦ Noise Level: 0.008PCrms + 0.005pCRMS per 1, 000pF of source
capacitance referred to input or 5mVrms referred to
output , which is greater.
¦ Accuracy: Within ± 1.5% throughout the whole range at 1, 000Hz
and at 1, 000pF or lower in input capacity.
¦ Overload Indication: The overload warning lamp lights up when exceeding
the linear sphere.
¦ Temperature/ Humidity Range: -20° C + 60° C( 0.05% / ° C) , 90% RH or lower.
¦ Power Supply: ± 9V to ± 15V, 20mA Max.
¦ Dimensions and Weight: 34.5( W) × 99( H) × 152( D) mm, 1, 000g.
¦ Accessories
Power Supply Units: Dimensions and weight: 69( W) × 99( H) × 152( D) mm,
1, 000G.
Model-4035-10M: For 100VAC, complete with CAL signals and 10CH
Switching AC Meter, for 10CH Max.
Model-4035-16M: For both 100VAC and 12VDC.
